960W Single Output Industrial DIN RAIL with PFC Function

NDR- 960 series
AC input 180~264VAC only130% peak load capability1 10mm slim design Built-in active PFC function compliance to EN61000-3-2 High efficiency 94% and low power dissipation.
Overview
Specifications
Connectivity Solutions
Models
Resources

Features

● AC input 180~264VAC only

● 130% peak load capability

● 110mm slim design

● Built-in active PFC function compliance to EN61000-3-2

● High efficiency 94% and low power dissipation

● Protections: Short circuit /Overload/Over voltage /Over temperature

● Cooling by free air convection

● Built-in constant current limiting circuit

● Can be installed on DIN rail TS-35/7.5 or 15

● UL508(industrial control equipment)approved

● EN61000-6-2(EN50082-2)industrial immunity level

● Current sharing up to 3840W(3+1)

● Built-in DC OK relay contact

● 100% full load burn-in test

● 3 years warranty

MODELSDR-960-24SDR-960-48
OUTPUTDC VOLTAGE24V48V
RATED CURRENT40A20A
CURRENT RANGE0 ~ 40A0 ~ 20A
RATED POWER960W960W
PEAK CURRENT52A26A
PEAK POWER                 Note.61248W (3sec.)
RIPPLE & NOISE (max.)  Note.2180mVp-p250mVp-p
VOLTAGE ADJ. RANGE24 ~ 28V48 ~ 55V
VOLTAGE TOLERANCE  Note.3±1.0%±1.0%
LINE REGULATION±0.5%±0.5%
LOAD REGULATION±1.0%±1.0%
SETUP, RISE TIME1000ms, 100ms/230VAC at full load
HOLD UP TIME (Typ.)14ms / 230VAC at full load
INPUTVOLTAGE RANGE          Note.7180 ~ 264VAC          254 ~ 370VDC
FREQUENCY RANGE47 ~ 63Hz
POWER FACTOR (Typ.)PF≥0.95/230VAC at full load
EFFICIENCY (Typ.)94%94%
AC CURRENT (Typ.)6A/230VAC
INRUSH CURRENT (Typ.)COLD START 50A / 230VAC
LEAKAGE CURRENT<3.5mA / 240VAC
PROTECTION
Normally works within 105 ~ 130% rated output power for more than 3 seconds and then shutdown o/p voltage with auto-recovery after 30 seconds if the peak load condition is removed
OVERLOADConstant current  limiting within 130 ~ 150% rated output power for more than 3 seconds and then shutdown o/p voltage, re-power on to recover
OVER VOLTAGE29 ~ 33V56 ~ 65V
Protection type : Shutdown o/p voltage, with auto-recovery or re-power on to recover
OVER TEMPERATUREShutdown o/p voltage, recovers automatically after temperature goes down
FUNCTIONDC OK REALY CONTACT RATINGS (max.)60Vdc/0.3A, 30Vdc/1A, 30Vac/0.5Aresistive load
CURRENT SHARINGPlease refer to function manual
ENVIRONMENTWORKING TEMP.            Note.5-30 ~ +70℃ (Refer to "Derating Curve")
WORKING HUMIDITY20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY-40 ~ +85℃ , 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT±0.03%/℃ (0 ~ 50℃)
VIBRATIONComponent:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X,Y, Z axes; Mounting: Compliance to IEC60068-2-6
SAFETY &SAFETY STARDSUL508,TUV EN62368-1 , BSMI CNS14336-1, AS/NZS62368.1 , EACTPTC 004 approved ; (meet EN60204-1)
EMCWITHST VOLTAGEI/P-O/P:3KVAC     I/P-FG:2KVAC     O/P-FG:0.5KVAC     O/P-DC OK:0.5KVAC
(Note 4)ISOLATION RESISTANCEI/P-O/P, I/P-FG, O/P-FG:>100M Ohms / 500VDC / 25℃/ 70% RH

EMC EMISSION               Note.8Compliance to EN55032 (CISPR32), EN61204-3 Conduction class B, Radiation class A, EN61000-3-2,-3, EACTPTC 020, BSMI CNS13438

EMC IMMUNITYCompliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN61000-6-2 (EN50082-2), EN61204-3, heavy industry level, criteria A, EACTPTC 020
OTHERSMTBF69.8K hrs min.      MIL-HDBK-217F (25℃)
DIMENSION110*125.2*150mm (W*H*D)
PACKING2.47Kg ; 6pcs/15.8Kg/1.55CUFT
NOTE1. AII parameters NoT speciaIIy mentioned are measured at 230VAC input, rated Ioad and 25℃  of ambient temperature.
2. RippIe & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf paraIIeI capacitor.
3. ToIerance : incIudes set up toIerance, Iine reguIation and Ioad reguIation.
4. The power suppIy is considered a component which wiII be instaIIed into a finaI equipment. The finaI equipment must be re-confirmed that it stiII meets EMC directives.
5. InstaIIation cIearances : 40mm on top, 20mm on the bottom, 5mm on the Ieft and right side are recommended when Ioaded permanentIy with fuII power. In case the adjacent device is a heat source, 15mm cIearance is recommended.
6. 3 seconds peak power max. and the average output power shouId not exceed the rate power.
7. Derating may be needed under Iow input voItage. PIease check the derating curve for more detaiIs.
8. ConsuIt MEAN WELL for depIoyment of Radiation cIass B.
9. The ambient temperature derating of 3.5℃ 1000mwithfanIessmodeIsandof5/1000m with fan modeIs for operating aItitude higher than 2000m(6500ft). ※ Product LiabiIity DiscIaimer :For detaiIed information, pIease refer to https://www.meanwell.com/serviceDisclaimer.aspx
